Schedule
5 Gaskets
Components are
used in processing pipeline systems for the food, dairy, beverage, pharmaceutical
and bio tech industries. The products are manufactured from EPDM, Viton®,
Buna-N, and Silicone, as well as gaskets made with Teflon® fluoropolymer.
All compounds are FDA compliant. |
|
|
|
|
|
|
|
![](graphic/40MV-U.jpg) |
Schedule
5 Standard Tri-Gaskets |
40MV-U
40MV-SFY
40MV-E
40MV-X
40MV-G |
Buna-N
Viton®
EPDM
Silicone
Teflon® fluoropolymer |
1",
1 1/2", 2", 2 1/2", 3" & 4" |
![](graphic/40MVF-U.JPG) |
Schedule
5 Flanged Tri-Gaskets |
40MVF-U
40MVF-SFY
40MVF-E
40MFV-X
40MV-G |
Buna-N
Viton®
EPDM
Silicone
Teflon® fluoropolymer |
1",
1 1/2", 2", 2 1/2", 3" & 4" |
![](graphic/40mv-gr.jpg) |
Schedule
5 Tri-Clamp Envelope Gaskets made
with Teflon® fluoropolymer |
A40MV-GR
|
Teflon®
fluoropolymer
standard EPDM fillers
(also available
with
Viton fillers) |
1",
1 1/2", 2", 2 1/2", 3", 4" & 6" |
|
|
|
|
|
|
|
|
|
|
|
![](graphic/Tri-Clamp-Schedul-5-dimensi.jpg) |
|
|
|
|
|
|
|
Double
click on the graphic above to open a PDF file of our Schedule 5 Tri-Clamp Gasket
Dimensions. |
|
|
|
|
|
|
|
Viton® is a registered trademark of DuPont Performance
Elastomers. Teflon® is a registered trademark of DuPont. |
|
|
